The GelSight Benchtop Scanner can quickly capture the surface geometry of almost any material regardless of its optical properties. This capability is due to the GelSight sensor, a small block of elastomer with a reflective coating on one side. The unique properties of the GelSight sensor remove the influence of the optical characteristics of the material on the measurement, thereby ensuring accuracy, repeatability, and consistent performance, even on optically complex surfaces.
SEM-like images: GelSight images are often compared to images from a scanning electron microscope (SEM) because both systems reveal surface structure without being influenced by the surface's optical characteristics. While SEMs offer amazing resolution, they operate in vacuum, require elaborate sample preparation, and typically only capture a small field of view. For imaging at the micron scale and above, GelSight can capture comparable images with much less time and effort.
Fast 3D: Unlike scribe profilometers and other scanning technologies, GelSight 3D scanners capture the entire surface in just a few images. Fast acquisition means no measurement drift, less sensitivity to vibration, no sensitivity to environmental changes (e.g., temperature), and fast, reliable results.
Repeatability: The GelSight sensor removes the influence of the optical properties of the material on the measured geometry. You can expect high-quality, reliable results on almost any material, such as glass, plastic, metal, as well as combinations of materials.
GelSight measurements of various materials.
Accuracy: GelSight 3D scanners measure depth to submicron accuracy.
Technical Specifications: Our standard configuration offers an 18-megapixel camera and 1X-5X magnification which meets the needs of many applications. This setup has the following specifications:
  • Sensor resolution: 18-megapixels (5202 x 3465 pixels)
  • Optical magnification range: 1X - 5X
  • Field of view:
    • 1X: 22.4 mm x 14.9 mm
    • 2X: 11.2 mm x 7.4 mm
    • 3X: 7.5 mm x 5.0 mm
    • 4X: 5.6 mm x 3.7 mm
    • 5X: 4.5 mm x 3.0 mm
Purchase: Please contact us to discuss your measurement needs and to request a quote. If our benchtop system is not appropriate for your application, we would be happy to discuss custom solutions built around our technology.
